Syfer has added higher voltage ceramic capacitors to its AEC-Q200 series of MLCCs, extending maximum working voltage in the series from 2kV up to 4kV. “Designed for electric vehicle applications where ever higher voltages are needed, but where a margin for derating has to be accommodated for, they are ideal for power train use, like battery management and invertors,” claimed ...
Infineon has availability of a new member of its CoolMOS P7 family, the 950 V CoolMOS P7 Superjunction MOSFET. The chip has improved DPAK R DS(on) enabling higher density designs. Similar to the other members of the P7 family from Infineon, it comes with an integrated Zener diode ESD protection. This results in better assembling yields, less cost, and less ESD ...
“Historically, p-channel jfets availability has declined,” according to Californian fet maker Linear Integrated Systems (LIS). “Complementary single n-channel and p-channel jfets have become limited to a few industry standards. Complementary monolithic dual n-channel and p-channel jfets have not been offered for many years, leaving designers under supported.” And its answer to the dearth of choice is the LSJ689, a 1.8nV/Hz (at 1kHz) ...
Intended for protecting op-amp, sample-and-hold and multiplexer inputs, Linear Systems has created a range of extremely low-leakage picoamp diodes (PADs) with reveres currents ranging from 1pA to 100pA, which are “pin-for-pin replacements for Siliconix-Vishay”, said Linear. They are available in: TO-92 two-lead (part name = JPAD, 35Vmax reverse) TO-72 (PAD, 45Vmax) SOT-23 (SSTPAD 30V) DFN eight-lead (PAD-DFN, 30Vmax) The leakage in ...
Toshiba has launched a Schottky barrier diode aimed at rectification and back-flow prevention. Called CUHS10F60, due to the newly developed 2.5 x 1.4mm US2H package (SOD-323HE) it features a thermal resistance of 105°C/W. “The package’s thermal resistance has been reduced by about 50% compared to the conventional USC package,” said the firm. In comparison to Toshiba’s earlier CUS04 Schottky diode, maximum reverse ...
Toshiba is in volume production of MOSFETs that incorporate an active-clamp structure
Infineon is in volume production of an expanded portfolio of thin-wafer TRENCHSTOP 5 IGBTs
New Jersey-based UnitedSiC has introduced a 40mΩ silicon carbide transistor
Infineon is in volume production of the IM512 and IM513 series of the CIPOS Mini family. They are the first high efficient IPMs (intelligent power modules) that integrate CoolMOS MOSFETs. The IPMs help in optimizing power efficiency in applications such as compressors, pumps or fans for home appliances. The chips are designed to drive motors up to 600 W. They ...
Taiyo Yuden has squeezed 1,000μF into a 2.5V multi-layer ceramic capacitor only 4.5 x 3.2 x 3.2mm.
