Designed for space-saving and embedded platforms, the OSM-S AM62L is aimed at applications such as smart home systems, patient monitoring systems, EV charging stations, and solar gateways.
OSM-S AM62L Specification
Clocking 1.25 GHz, Kontron’s system-on-module is compliant with the OSM standard and supports 512MB to 2GB LPDDR4 RAM as well as 4GB to 128GB eMMC flash storage.
A MIPI-DSI and an RGB interface are available for human-machine interfaces. And for comms, there are two Gigabit Ethernet ports and two CAN FD interfaces.
In more detail, features of the SoM include:
- CPU TI AM62L, 2x Arm Cortex-A53 @1,25 GHz
- LPDDR4-RAM 1 GByte, optional 512 MByte, 2 GByte
- eMMC 4 GByte, optional up to 128 GByte
- EEPROM 8 kByte
- Ethernet 2x 1 Gbit/s IEEE 1588 (with TSN)
- USB 2x USB 2.0 (Host or Device)
- I/O 5x UART, 2x I²C, 2x SPI, 15x GPIO, 3x PWM, 1x SAI, 2x SDIO 4-bit, 2x ADC
- CAN 2x CAN FD
- Display Interface 1x MIPI DSI (4-lane), 1x RGB 18 bit, Up to 1920 x 1080 @60 fps
- Power supply 5 V DC ±5 %
- IO voltage TBD
- Power consumption TBD
- Temperature range -25 °C to +85 °C, ambient, non-condensing
- RTC (I²C) 45 nA/1ppm @25 °C
- Operating system Embedded Linux (Yocto Distribution)
- Form factor 30 x 30 mm OSM Size S
- Footprint 332 Pin/1,25 mm pitch
- Security Secure boot, Trusted Execution Environment (TEE), Dedicated Security Controller, AES – 128-/192-/256-bit, SHA2 – 224-/256-/384-/512-bit, DRBG, PKA
TI
It is the first time Kontron Electronics has introduced a SoM module with a Texas Instruments processor, as opposed to Intel or AMD.
Initial customer samples of the OSM-S AM62L system-on-module will be available from Q2 of 2026.
Kontron Electroincs Group headquarters are in Ismaning. It also has offices in San Diego, Montréal, Beijing and Taipei.
Image: Kontron Electronics
