Toshiba’s TPHR6704RL is a 40V, 0.67mΩ N-channel MOSFET aiming yo to improve efficiency for industrial power supplies. It uses U-MOS11-H technology, highlights Toshiba, to deliver ultra-low on-resistance, fast switching and improved EMI performance in switched-mode power supplies. For example, by minimising voltage spikes generated between the drain and source during switching. TPHR6704RL The company writes: “By adopting the U-MOS11-H process, ...
Recom’s new range of power ICs and SMD (Surface Mount Device) transformers, for building discrete DC/DC isolated power supplies, includes the RVP6501. This is a pin-compatible second-source alternative to the 6501-type push-pull transformer driver IC. The company highlights the two features of precise switch timing and over-current protection. This, it says, is to avoid the risk of flux imbalance core ...
Toshiba is expanding its DTMOSVI series lineup – for switched-mode power supplies for industrial equipment – with DTMOSVI 600V HSD (High-Speed Diode) N-channel power mosfets. Featuring a super junction structure, the seven new products are available in TO-247, TOLL and DFN8×8 packages. TK058V60Z5 The company highlights the TK058V60Z5, featuring an ultra-low drain-source on-resistance (RDS(ON)) of 0.050Ω (typ.) in a DFN8×8 ...
Nisshinbo Micro Devices has announced the NT9000/NT9001/NT9002/ NT9003 series of dual diode devices designed for Wireless Power Transfer (WPT). The new series utilises the company’s proprietary GaAs wafer process technology and is designed to support highly efficient rectification in WPT systems by combining low forward voltage with high DC withstand voltage, enabling improved conversion efficiency over a wide dynamic range. ...
Nisshinbo Micro Devices has brought out the NT1199, a high-linearity GNSS wideband low noise amplifier (LNA) that enables low current consumption and high performance for multi-band GNSS applications.i The device operates across a frequency range from 1164 MHz to 1610 MHz. It has a high gain of up to 17.5 dB in the L1 band and 18.0 dB in the ...
At Space-Comms Expo, Filtronic was highlighting the latest version of its Cerus V solid state power amplifier (SSPA) for long range V-Band comms. This is for high-frequency links across land, air and space. One application, for example, is for satellite ground stations, providing a gateway to link to LEO. And other sectors cited by the RF-to-mmWave specialist include defence and ...
Omron’s S8AS2 compact smart power supply combines DC power supply, electronic circuit protection, and real-time monitoring in one panel-mountable unit. Reducing the number of components required in the control cabinet will simplify panel design and wiring, highlights the company. Factory automation and industrial control applications are the main target for the system. S8AS2 features UL Class 2 output compliant, the ...
Rohm is using its new HPLF5060 package (4.9mm × 6.0mm) to expand its lineup of low-voltage (40V/60V) MOSFETs for automotive applications. For example, main inverter control circuits, electric pumps, and LED headlights. Parts include the AG040FGS4FRA, the AG142FGS4FRA and AG543EGS4FRA, under the company’s EcoMOS brand. HPLF5060 package Rohm highlights the trend for automotive low-voltage MOSFETs moving towards smaller packages. It ...
ABLIC has launched the S-19760/1 Series automotive shunt reference ICs, which claims to achieve the industry’s highest output voltage accuracy of ±0.1% and the industry’s lowest output voltage temperature coefficient of ±20ppm/℃. The S-19760/1 Series is primarily used as a reference voltage for A/D converters, which convert analog sensor signals into digital values. The key features of the S-19760/1 Series ...
Toshiba has launched the ST2000JXH35A, a new 6500V/2000A press pack injection enhanced gate transistor (IEGT) designed for high-voltage converters used in DC power transmission systems, industrial motor-drive equipment, and static synchronous compensators (STATCOM). The device uses trench-type IEGT ICs with an optimised cell structure to deliver high turn-off capability and robust short-circuit withstand performance. These technical enhancements enable the device to ...
